Technical Characteristics
Technical Characteristics
Protocol supported |
STP, IP, ICMP, TCP, UDP, ARP, FTP, TFTP, DNS, HTTP, SNMP, MIB II, NAT, PAT, DHCP, VLAN (802.1q), PPPoE, SIP |
Functional |
Router / Bridge mode, IP-Filtering, Smart Ethernet Switch , 24 Line PABX, SIP v2.0 Gateway |
Connections |
6 10/100Base-TX 2 100Base-FX, 32 FXO/FXS (optional), 1 E1 (R1.5, EDSS) (optional) |
Managment |
WEB, SNMP, SNMP Trap |
Speech coding |
G.711, ACELP 4,8, G.729ab |
Statistics |
By every Ethernet Port. Calls of PABX and SIP gateway. |
Dimensions |
380x260x105 (19″ rack 1U) ~7Kg |
Power supply |
110/220V ~50Hz |
Features
As a switch, LAN:
- Implementation of STP protocol
- Collection of statistics (onsent/received Ethernet frames) via each port and its transmission to external equipment
- Control the status of Ethernet connections and automaticaly send the SNMP message on connection / disconnection to external equipment
- Control of parameters via SNMP (version 2) protocol: configuration and state of ports, port priority command on/off, establishment of priority levels via ToS, port based VLAN mode on/off, input and output flow rate of each port.
As an IP-router:
- Filtration of IP packets via SNMP (version 2) protocol to the complete criteria set
- Translation of network addresses according to the NAT (network address translation) and PAT (port address translation) technology
- Support of traffic priorities: via ToS fields, via IP-address of receiver and sender
- Support of dynamic routing
- Collection and transmission of statistics via IP, TCP, UDP, ICMP protocols and IP-network usersџ Control of parameters via assigned interfaces: filtering, network address translation, priorities and other functions.
As an IP-PBX:
- Establishment of connections between internal FXS users
- Establishment of connections via SIP protocol
- Support of modes of proxy server and SIP customer
- Connection of payphones via FXS interface and provision of connection with payphone management center via IP channel
- Simultaneous implementation of up to 12 connections with 8 Kbit/s codec, 4.8 Kbit/s ACELP to operate on low-speed IP-channel
- Control of equipment parameters and line features, user rights, SIP protocol settings, speech coding mode via SNMP (version 2) protocol.
As a E1 gateway:
- Transformation of speech and service information, received from PBX in terms of bit transfer rate, into IPflow and reverse transformation from IP-flow into bit transfer rate
- Support of protocols of telephone signaling: R 1.5 and EDSS1
- Support of protocol of SIP 2.0 IPtelephony network signaling
- Two-way conversion of telephone signaling into IP-telephony network signaling
- Coding of speech in synchronic mode according to the G.711 recommendation
- Coding of speech in packet mode according to the G.711, ACELP 4.8, G.729ab recommendation
